Raingun Sprinkler

Specification:

• Flow Rates (lpm)134 to 261
• Working Pressure (kg/cm²)4.0 to 4.5
• Wetted Diameter (m)21.0 to 26.0

Applications:

• Suitable for field crops like pulses, oil seeds, vegetables, sugarcane, cotton, cereals, tea, coffee and fodder crops.

Specification:

• Flow Rates (lpm)134 to 261
• Working Pressure (kg/cm²)4.0 to 4.5
• Wetted Diameter (m)21.0 to 26.0

Applications:

• Suitable for field crops like pulses, oil seeds, vegetables, sugarcane, cotton, cereals, tea, coffee and fodder crops.

Specification:

• Flow Rates (lpm)17.23 to 46.57
• Working Pressure (kg/cm²)2.0 to 4.0
• Wetted Diameter (m)13.0 to 15.0

Applications:

• Suitable for field crops like pulses, oil seeds, vegetables, sugarcane, cotton, cereals, tea, coffee and fodder crops

Specification:

• Flow Rates (lps)1.37 to 7.17
• Working Pressure (kg/cm²)2.0 to 6.0
• Wetted Radius (m)19.5 to 34.5

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc

Specification:

• Flow Rates (lps)1.37 to 7.17
• Working Pressure (kg/cm²)2.0 to 6.0
• Wetted Radius (m)19.5 to 34.5

Applications:

• For dust suppression, mining or environmental applications.

Specification:

• Flow Rates (lpm): 570 to 1180
• Working Pressure (kg/cm²): 2.0 to 4.0
• Wetted Diameter (m): 11.5 to 14.0

Applications:

• Suitable for field crops like pulses, oil seeds, vegetables, sugarcane, cotton, cereals, tea, coffee and fodder crops.
• For efficient irrigation of field edges.

Specification:

• Flow Rates (lps)258.5 to 1849.8
• Working Pressure (kg/cm²)3.0 to 8.0
• Wetted Radius (m)35.0 to 63.5

Applications:

• For dust suppression, mining or environmental applications.

Specification:

• Flow Rates (lps)2.17 to 15.67
• Working Pressure (kg/cm²)2.0 to 6.5
• Wetted Radius (m)23.8 to 54.3

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc
• Easy to use with portable irrigation system
• Useful for large turfs, lawns and playgrounds

Specification:

• Flow Rates (lps)159.6 to 940.2
• Working Pressure (kg/cm>2)2.0 to 6.0
• Wetted Radius (m)27.9 to 54.4

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc.
• Easy to use with portable irrigation system
• Useful for large turfs, lawns and playgrounds

Specification:

• Flow Rates (lps)231.6 to 1524.6
• Working Pressure (kg/cm>2)2.0 to 7.0
• Wetted Radius (m)27.9 to 63.1

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc
• Easy to use with portable irrigation system
• Useful for large turfs, lawns and playgrounds

Specification:

• Flow Rates (lpm)339.6 to 2032.2
• Working Pressure (kg/cm²)2.0 to 7.0
• Wetted Radius (m)25.0 to 68.5

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc
• Easy to use with portable irrigation system
• Useful for large turfs, lawns and playgrounds

Specification:

• Flow Rates (lph)434.4 to 2654.4
• Working Pressure (kg/cm2)2.0 to 7.0
• Wetted Radius (m)37.2 to 71.8

Applications:

• Recommended for field crops like sugarcane, pulses, oil seeds, cereals, tea, coffee, vegetables, etc.
• Easy to use with portable irrigation system
• Useful for large turfs, lawns and playgrounds

Specification:

• Flow Rates (lph)130.2 to 903.6
• Working Pressure (kg/cm²)2.0 to 6.0
• Wetted Radius (m)22.1 to 52.4

Applications:

• The Trigon 112 is the only big volume gun specifically engineered for leach mining applications. Materials and components are carefully selected in order to withstand the corrosive medias used. It allows to safely leach side slopes of heaps otherwise unaccessable, maximizing the result of the leaching process. On flat leach terrain, the use of the Trigon reduces labor.
• The Trigon 105 was designed for specific waste-water applications. It features a free flow passage to prevent clogging of liquids containing suspended particles. Most common applications are: municipality waste-water systems, effluent waters from food processing plants, treated manure, sugar factories and many others. It is also salt water resistant, for applications in more aggressive chemical conditions.
