Emitter / Dripper

Specification:

• Nominal Discharges (lph): 2.2 , 4.2, 8.2
• Working Pressure (kg/cm²): 0.8 to 3.0

Applications:

• Recommended for open field application like orchards, fruit crops, vegetables, etc.
• Suitable for nurseries, pot irrigation & greenhouse irrigation.
• Recommended to use where section size is large and longer lateral length of run is required.
• Recommended for undulating terrain & steep slopes.
• Recommended to use in problematic water condition where cleaning of emitter is required.

Specification:

• Nominal Discharges (lph):8, 14
• Operating Pressure (kg/cm²): 1

Applications:

• Horticultural plants require high water volume requirements.
• In the greenhouse for potted plants.
• Row crops requiring continuous wetted stripes.

Specification:

• Nominal Discharges (lph) 2, 4, 8 ,14
• Working Pressure (kg/cm²) 1

Applications:

• For orchards and vineyards, greenhouses, nurseries, landscape etc.
• Recommended to use in problematic water condition where opening and cleaning of the emitter is needed.

Specification:

• Nominal Discharges (lph) 2, 4, 8 ,24
• Working Pressure (kg/cm²) 1

Applications:

• For orchards and vineyards, greenhouses, nurseries, landscape etc.
• For pulse irrigation and irrigation in soilless conditions.
• Prevents surplus drainage in low places (PCNL model)
• For areas with harsh topographical conditions.
• Subsurface installation protects dripper from animal damage

Specification:

• Nominal Discharges (lph): 2.0, 4.0, 8.0, 14.0
• Nominal Operating Pressure: 1 kg/cm²

Applications:

• For orchards and vineyards, greenhouses, nurseries, landscape etc.
• Recommended to use in problematic water condition where opening and cleaning of the emitter is needed.

Specification:

• Nominal Discharges (lph) 1.3, 2.0, 3.0, 4.0, 8.0, 12.0
• Working Pressure (kg/cm²): 0.5 to 4.0
• for PCNL model (kg/cm²): Opening Pressure - 0.8
  Closing Pressure - 0.3

Applications:

• For orchards, vineyards, greenhouses, nurseries and landscape.
• For pulse irrigation and irrigation in soilless conditions.
• Prevents surplus drainage in low places (PCNL model).
• For areas with harsh topographical conditions.
• Subsurface installation protects dripper from animal damage.
• For irrigation of pot-plants with single, two, four or multiple outlets.

Specification:

• Nominal Discharges (lph) 2, 3, 4, 8
• Working Pressure (kg/cm²): 0.6 to 4.0

Applications:

• For orchards and vineyards, greenhouses, nurseries, landscape etc.
• For areas with harsh topographical conditions.
• For irrigation of pot-plants with extension tube.
• Recommended to use where longer length of lateral is required.

Specification:

• Nominal Discharges (lph) 2, 3, 4, 8
• Working Pressure (kg/cm²): 0.6 to 4.0

Applications:

• For orchards and vineyards, greenhouses, nurseries, landscape etc.
• For areas with harsh topographical conditions.
• For irrigation of pot-plants with extension tube.
• Recommended to use where longer length of lateral is required.

Specification:

• Maximum Discharge (lph): - 0 to 50, 0 to 100
• Opening Pressure (cm) - 1kg/cm²

Applications:

• Suitable for trees having high water requirement.
• Recommended for sandy soils / desert conditions.
• Can also be used for lower pressure.

Specification:

• Nominal Discharges (lph): 2.1
• Working Pressure, kg/cm²: 1

Applications:

• Suitable for pot irrigation, nurseries, glass/green houses, vegetables, home gardens.

Specification:

• Nominal Discharges (lph): 2.1
• Working Pressure, kg/cm²: 1

Applications:

• Suitable for pot irrigation, nurseries, glass/green houses, vegetables, home gardens.

Specification:

• Nominal Discharges (lph): - 1.5, 4.0, 8.0
• Operating Pressure (kg/cm²): 1

Applications:

• Suitable for pot irrigation, nurseries, glass/green houses, vegetables, home gardens.

Specification:

• Nominal Discharge (lph): 11.4, 15.9, 25.0, 43.1, 56.8
• Opening Pressure (cm) - 1.4kg/cm2

Applications:

• Recommended for open field application like orchards, fruit crops etc.
• Suitable for nurseries, pot irrigation & greenhouse irrigation.

Specification:

• Nominal Discharges (lph):2.0, 4.0, 8.0
• Operating Pressure (kg/cm²): 1

Applications:

• Recommended for fruit orchards requiring multiple drippers around the trunk of the tree, to cover widespread root zone.

Specification:

• Sizes (mm) 16
• Nominal Discharges (lph) 2.2, 4.0

Applications:

• Ideal for irrigation of closely spaced row crops like sugarcane, cotton, banana, vegetable, strawberry, spices, biofuel crops, floriculture, etc.
• Suitable for surface as well as sub-surface irrigation.
• Recommended to use in greenhouses and nurseries.
• Used for widely spaced horticultural plants like mango, citrus, guava, apple etc. in group spacings.

Specification:

• Nominal Discharges (lph) : 16mm - 1.1, 1.6, 2.2, 3.5
  20mm - 0.9, 1.6, 2.2, 3.8
• Pressure Compensating Range0.8 to 4 kg/cm² (7 to 71 psi)

Applications:

• Ideal for irrigation of closely spaced row crops like sugarcane, cotton, banana, strawberry, floriculture, vegetables and spices.
• Suitable for surface as well as sub-surface irrigation.
• Recommended for undulating terrain & steep slopes and where longer lateral running length is necessary.
• Open field application to maintain high field application efficiency.
• Suitable for low operating pressure/ Gravity feed irrigation system.
